Steel Detailing
CadMan has very vast experience in steel detailing. All our drawings and reports are customized to suit your shop requirements. Our aim is to make sure our customer gets appreciation from his customer for successful projects.
We provide complete detailing services for all types of Main & Misc. Metal work for industrial, commercial structures, including stairs, rails, and many other structures.
DELIVERABLE
- Advance Bill of Materials
- Anchor bolt drawings
- Embed drawings
- Erection drawings
- Shop drawings
- Shop and field bolt lists
- NC files
- DXF files
- FabTrol / EJE files
- Transmittal
- Drawing Log
- 3D model
- Design calculations
PEMB Detailing
CadMan is a leading Engineering firm in Pre-engineered Metal Building (PEMB) detailing services. We design and detail Pre-Engineered Metal Buildings and Hybrid Structures ranging from small to large structures by following AWS, AISI, ASTM, MBMA and IAS & SSMA codes. We can design and detail drawings for PEMB/PEB or any other combination of services. We produce high quality drawings with an on-time schedule.
Estimation
CadMan provides the presided estimation with on time and competitive cost. We do material take-off as per customer.
DELIVERABLE
- Detailing cost and schedule
- Material Take-off cost
- Connection engineer (PE/SE) cost
Joist & Deck
CadMan offer joist and deck detailing services for various types of joists. Our service includes joist girders, bridging, open web joist, deck, and accessories. We create detailed shop drawings that include deck profiles, reinforcement layout, embedment details, and connections to support structural loads.
Connection Design & Stamping
In addition to steel detailing CadMan provides design for USA & Canada.
DELIVERABLE
- Design calculations
- Connection design sketches with markup plans
- ES /PE Stamping (Optional)
